最簡單的方法製造一個頻率隨時間改變的 cos 波形

http://mqjing.blogspot.com/2017/11/cos.html

How to create a signal that frequence changes in time
井民全, Jing, mqjing@gmail.com
ETA: 5 min
Back to the Main Page
Download: notebook
Google doc: This Document

Purpose

這篇文章教你理解如何建立一個 chirp 訊號類別, 理解如何製造一個頻率隨時間改變的訊號.
Fig. The cos(2π f(t) t) signal in time 1 sec.

Key

  • 重點就是如何回傳 evaluate function 的 ys 值.
  • 因為 frequency 隨時間改變, 所以在建立訊號時, 要
    • Step 1: [計算 phase] 先計算每個 time interval 個別的 phase, dph
    • Step 2: [計算 amplitude] 得到了 sample 在時間 axis 上的位置, 根據 phase 計算 signal 的 amplitude.

Usage

signal = Test2(start=10, end=200) # 產生 signal, 給定頻率 從 10 到 200


# 測試聲音
wave1 = signal.make_wave(duration=4)    # 建立 4 秒鐘,波形
wave1.make_audio()
Fig. A audio control for play the chirp signal.

# 畫出波形檢視
wave1.segment(start=0, duration=1).plot()  # 只看 1 秒鐘這範圍的波形 y
Fig. Show the customized signal for 1 second

Show me the code

from __future__ import print_function, division

%matplotlib inline

import thinkdsp
import thinkplot
import numpy as np

import warnings
warnings.filterwarnings('ignore')

from ipywidgets import interact, interactive, fixed
import ipywidgets as widgets

from thinkdsp import Signal
import math

class Test2(Signal):
   def __init__(self, start, end, amp=1.0):
       self.start = start
       self.end = end
       self.amp = amp

   def evaluate(self, ts):
       # ts maybe very tinny
       # Create a data list for recording the frequency for each interval in time
       freqs = np.linspace(self.start, self.end, len(ts) - 1)

       # Step 1: Setup the phase (the position of a point in time on a wavefrom cycle)
       # Since the frequence is variance in time, we should calcuate the phase
       # for each interval, individually.
       dts = np.diff(ts)                              # (a) Get the time intervals in time
       dps = math.pi * 2 * freqs * dts     # (b) Calcuate the individual phases for each interval
       phases = np.cumsum(dps)          # (c) Accumuate the individual phases to form the
                                                                 #       phrases in time for a wavefrom

       # Step 2: Setup the amplitude
       ys = self.amp * np.cos(phases)      # Calcuate the amplitude sequence for given phases
       return ys


如何建立 ThinkDSP class 處理自訂的訊號, 接上 DSP 工具進行快速分析

http://mqjing.blogspot.com/2017/11/thinkdsp-class-dsp.html

How to create a class for customized signal
井民全, Jing, mqjing@gmail.com
Back to the Main Page
Google doc: This Document
ThinkDSP 套件提供了許多方便的 DSP 工具, 幫你產生聲音, 產生波形讓你檢視, 進行頻譜分析, 高通低通濾分析, 實在很好用.

Purpose

這篇文章教你如何建立一個最簡單的類別, 封裝你自訂的訊號, 然後就可以接上 ThinkDSP的各項功能, 進行訊號分析.

Key

  • 重點就是如何回傳 evaluate function 的 ys 值, 其中 evaluate function 會給你 t 參數.
  • 當然, 你得懂甚麼叫做 phase

Usage

signal = Test(f=1)  # 給定頻率 = 1


# 測試聲音
wave1 = signal.make_wave(duration=4)    # 建立 4 秒鐘,波形
wave1.make_audio()
Fig. A audio control for play the customized signal.

# 畫出波形檢視
wave1.segment(start=0, duration=2).plot()  # 只看 2 秒鐘這範圍的波形 y
Fig. Show the customized signal for 4 second

Show me the code

from __future__ import print_function, division

%matplotlib inline

import thinkdsp
import thinkplot
import numpy as np

import warnings
warnings.filterwarnings('ignore')

from ipywidgets import interact, interactive, fixed
import ipywidgets as widgets

from thinkdsp import Signal
import math

# Define the my signal class for handling my customized signal
# Here, a simple cos signal is implemented.
class Test(Signal):
   def __init__(self, f, amp=1.0):
       self.f = f
       self.amp = amp

   def evaluate(self, ts):
       phase = math.pi * 2 * self.f * ts       # phase = 2\pi f t
       ys = self.amp * np.cos(phase)        # computes the amplitude of the wave as a function of phase
       return ys

2017年10月28日 星期六

ThinkDSP, a very good DSP material

http://mqjing.blogspot.com/2017/10/thinkdsp-very-good-dsp-material.html

ThinkDSP
井民全, Jing, mqjing@gmail.com
Back to the Main Page
ETA: 30 mins

Google doc: This Document

ThinkDSP 這本書從觀念開始了解數位訊號處理, 讓你可以寫程式觀察訊號的前後變化.

Purpose

這份文件的目的是讓你在 30 分鐘內, 建立學習數位訊號處理的環境.

Text Book

Setup Development Environment

Step 1: Install TensorFlow using Anaconda (view)
Step 2: Pull the source

Verification

Step 1: Start Jupyter
jupyter notebook

Step 2: Coding
from __future__ import print_function, division

%matplotlib inline

import thinkdsp
import thinkplot

import numpy as np

#import warnings
#warnings.filterwarnings('ignore')

from ipywidgets import interact, interactive, fixed
import ipywidgets as widgets
from IPython.display import display

# Initial sin and cos signal
cos_sig = thinkdsp.CosSignal(freq=440, amp=1.0, offset=0)
sin_sig = thinkdsp.SinSignal(freq=880, amp=0.5, offset=0)

# plot cos signal
cos_sig.plot()
thinkplot.config(xlabel='Time (s)')


See
Ctrl + [Enter]
Result
Fig. The sin signal.

2017年10月26日 星期四

Digital number recognition

http://mqjing.blogspot.com/2017/10/digital-number-recognition.html

MNIST for ML Beginners
Digital number recognition
井民全, Jing, mqjing@gmail.com
ETA: 30 mins
Back to Main Page

Google doc: This document.

Purpose

利用這份文件, 你可以開始撰寫第一支 tensorflow 程式, 並且建立信心. 每一個學習 tensorflow 的朋友, 都應該看過 MNIST digital number recognition 的官方教學文件 [1]. 所以, 我把它變成 step by step 步驟. 按照這個步驟可以在 30 分鐘內, 完成下列目標:
  1. 建立 tensorflow 開發環境.
  2. 完成官方教學文件的 tensorflow 程式碼, 開始玩 number recognition.

Abstract

給定一張影像, 乘上不同的模板, 取得得分最高者. 訓練的目的在於能夠產生最佳分辨的模板.

Point

容易搞混的地方在 tensorflow 的陣列描述.

Table of Contents



Setup Environment

  1. [install, Anaconda] How to install TensorFlow using Anaconda (view)

Download the MINST Data

Code

from tensorflow.examples.tutorials.mnist import input_data
mnist = input_data.read_data_sets("MNIST_data/", one_hot=True)

E.g.
Fig. Python Code for Download the Database.
Fig. Downloaded MNIST Database.

MNIST Database Info

Training Set & Testing Set & Validation Set

Items
Number
Comments
Training data
55,000 data points

Testing data
10,000 data points

Validation data
5,000 data points


MINIST Data Point Info

Handwrite Digit Image, x
Label, y
mnist.train.images


28 x 28 =  784

(784-dimensional vector space)
mnist.train.labels

1

Data Structure for Represent Data

Items
Number
Data
Training data, Image Part,
mnist.train.images
55,000

[55000, 784]

  1. the index into the list of images
  2. the index for each pixel in each image
  3. between 0 and 1

Training data, Image Part,
mnist.train.labels
55,000
[55000, 10]

Format: one-hot vectors
3 => [0, 0, 0, 1, 0, 0, 0, 0, 0, 0]

Testing data
10,000 data points

Validation data
5,000 data points



Making Model

Softmax Regressions

Purpose: We want to be able to look at an image and give the probabilities for it being each digit. (ex: Give a picture of a nine be 80% sure it's a nine, but give a 5% chance to it being a eight, ...)
Model: Assign probabilities to an object being one of several different things
When to use Softmax: Gives us a list of values between 0 and 1 that add up to 1. Even later on, when we train more sophisticated models, the final step will be a layer of softmax.

The Process of Softmax

  1. add up the evidence of our input being in certain classes
  2. convert that evidence into probabilities
The weights learned for each of these classes. (Red: negative weight, Blue: positive weight)
Bias: represent the things are independent of the input.

Calcuate the evidence for a class i


  • is the weight for class
  • is the bias for class
  • is the index for summing over the pixels in our input image

Convert the evidence to probabilities y

Shaping the output of our linear function into the probability distribution over 10 cases.

Define the softmax
= softmax()

softmax() = normalize(exp(x))

Exponentiation means
  • One more unit of evidence increases the weight given to any hypothesis multiplicatively
  • One less unit of evidence means that a hypothesis gets a fraction of its earier weight
Normalize
  • so that weights add up to one forming a valid probability distribution

Calcuating evidences for all classes and convert

We (1) compute a weighted sum of the xs, (2) add a bias, and (3) then apply softmax.

Data Flow form

  • is the index for summing over the pixels in our input image
  • is the weight for class
  • is the bias for class

(Edit)
Equation form



Matrix form
解釋:
Y: The probalities of classes for a given image X.
X: The pixel of X
B: bias
W: the trainined weigt for each class i

Compact form


Implement the Regression

Define the Model


Model
TensorFlow Python Code
x = tf.placeholder(tf.float32, [None, 784])
W = tf.Variable(tf.zeros([784, 10]))
b = tf.Variable(tf.zeros([10]))

y = tf.nn.softmax(tf.matmul(x, W) + b)
Detail

28 x 28 =  784

# X1 =  [x1, x2, x3, ..., x784],
# X2 = [x1, x2, x3, ..., x784], ...,
# X55000 = [x1, x2, x3, ..., x784]


x = tf.placeholder(tf.float32, [None, 784])

// None => a dimension of any length

W = tf.Variable(tf.zeros([784, 10]))
b = tf.Variable(tf.zeros([10]))

y = tf.nn.softmax(tf.matmul(x, W) + b)


(Edit)

Training

Define the Loss Function

Loss Function
TensorFlow Python Code

Where
  • y is our predicted probability distribution
  • y′ is the true distribution (the one-hot vector with the digit labels)
y_ = tf.placeholder(tf.float32, [None, 10])

cross_entropy = tf.reduce_mean(-tf.reduce_sum(y_ * tf.log(y), reduction_indices=[1]))


Note:
reduction_indices=[1]: let tf.reduce_sum adds the elements in the second dimension of y

Minimize the Lost

train_step = tf.train.GradientDescentOptimizer(0.5).minimize(cross_entropy)

Launch the Model

sess = tf.InteractiveSession()
tf.global_variables_initializer().run()   #init variable

Run 1000 times for traning model

for _ in range(1000):
 batch_xs, batch_ys = mnist.train.next_batch(100)    # 100 random samples from training set
 sess.run(train_step, feed_dict={x: batch_xs, y_: batch_ys})

Evaluating Our Model

Logic
TensorFlow Python Code
[True, False, True, True] => [1,0,1,1] => 0.75
correct_prediction = tf.equal(tf.argmax(y,1), tf.argmax(y_,1))

tf.cast(correct_prediction, tf.float32)
92%
accuracy = tf.reduce_mean(tf.cast(correct_prediction, tf.float32))

print(sess.run(accuracy, feed_dict={x: mnist.test.images, y_: mnist.test.labels}))

Source

mnist_softmax.py
# Copyright 2015 The TensorFlow Authors. All Rights Reserved.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
#     http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
# ==============================================================================

"""A very simple MNIST classifier.

See extensive documentation at
https://www.tensorflow.org/get_started/mnist/beginners
"""
from __future__ import absolute_import
from __future__ import division
from __future__ import print_function

import argparse
import sys

from tensorflow.examples.tutorials.mnist import input_data

import tensorflow as tf

FLAGS = None


def main(_):
 # Import data
 mnist = input_data.read_data_sets(FLAGS.data_dir, one_hot=True)

 # Create the model
 x = tf.placeholder(tf.float32, [None, 784])
 W = tf.Variable(tf.zeros([784, 10]))
 b = tf.Variable(tf.zeros([10]))
 y = tf.matmul(x, W) + b

 # Define loss and optimizer
 y_ = tf.placeholder(tf.float32, [None, 10])

 # The raw formulation of cross-entropy,
 #
 #   tf.reduce_mean(-tf.reduce_sum(y_ * tf.log(tf.nn.softmax(y)),
 #                                 reduction_indices=[1]))
 #
 # can be numerically unstable.
 #
 # So here we use tf.nn.softmax_cross_entropy_with_logits on the raw
 # outputs of 'y', and then average across the batch.
 cross_entropy = tf.reduce_mean(
     tf.nn.softmax_cross_entropy_with_logits(labels=y_, logits=y))
 train_step = tf.train.GradientDescentOptimizer(0.5).minimize(cross_entropy)

 sess = tf.InteractiveSession()
 tf.global_variables_initializer().run()
 # Train
 for _ in range(1000):
   batch_xs, batch_ys = mnist.train.next_batch(100)
   sess.run(train_step, feed_dict={x: batch_xs, y_: batch_ys})

 # Test trained model
 correct_prediction = tf.equal(tf.argmax(y, 1), tf.argmax(y_, 1))
 accuracy = tf.reduce_mean(tf.cast(correct_prediction, tf.float32))
print('===================')
 print(sess.run(accuracy, feed_dict={x: mnist.test.images,
                                     y_: mnist.test.labels}))

if __name__ == '__main__':
 parser = argparse.ArgumentParser()
 # parser.add_argument('--data_dir', type=str, default='/tmp/tensorflow/mnist/input_data',
                     help='Directory for storing input data')
# /home/jing/MNIST_data
parser.add_argument('--data_dir', type=str, default='/home/jing/MNIST_data',
                     help='Directory for storing input data')
 FLAGS, unparsed = parser.parse_known_args()
 tf.app.run(main=main, argv=[sys.argv[0]] + unparsed)

Verification

source activate tensorflow
python mnist_softmax.py

e.g.

More Test

batch_xs, batch_ys = mnist.train.next_batch(x)
x=
3000 => 92.13%
1000 => 92.14%
500 => 92.14%
100 => 91.69%
50 => 91.13%
10 => 85.9%

References


Further Reading


  1. 這不僅僅是另一個使用TensorFlow來做MNIST數字圖像識別的教程 (ref)
